HOPPER:
• Combination hopper for front feed (manual) and top feed (robotic)
• Hinged for easy opening for cleaning and servicing
NOISE CONTROL:
• Steel/plastic/steel laminate to reduce resonant noise
• Assembly engineered to meet 90 DBA or less
CUTTING
CHAMBER :
• Tangential feed design to reduce flyback
• Heavy duty welded steel construction
BEARINGS:
• Oversized
• Outboard mounted
• Self-aligning pillow block
• Separated from cutting chamber to eliminate heat build-up
• Separated from cutting chamber to eliminate fouling or grease contamination
or granulate
INLET
LOUVERS:
• PVC construction
• Easily removed for cleaning
• Vertical orientation to eliminate ‘splash out’
• Directs air flow at proper angle for even distribution into wet
deck
• Helps prevent air-born debris from entering cell
ROTOR:
• 3 blade open type
• Knives mounted at a steep angle to bed knives
• Knives mounted at a counter angle to the bed knives
• Precision scissor cut
KNIVES:
• 3 rotor knives
• 2 bed knives
• Manufactured of D2 high carbon/high chrome tool steel
SCREEN:
• Choice of 1/4" or 5/16" diameter holes reversible
SCREEN CRADLE:
• Hinged
• Drops open for easy cleaning and servicing
MATERIAL BIN:
• Metal bin for easy handling of material
• Vacuum unloading with loader wand
DRIVE:
• ODP motor
• V belt drive
ELECTRICAL CONTROLS:
• Magnetic starter with thermal overload
• Start/stop buttons
• Reduced voltage (120 volt) control circuit
• Nema 1 enclosure
SAFETY FEATURES:
• Hopper and screen cradle are electrically and mechanically interlocked
• Time delay safety bolt to prevent operation when machine is open
for service
|
